Center-Hung Suspension for Balanced, Guide-Free Operation
The Centerfold system suspends each panel from its center point rather than its edge, creating a balanced load on the overhead track. This design eliminates the need for a bottom guide channel across the full width of the opening. A single-side installation spans up to 19 feet 8 inches. An opposed installation (panels folding from both sides) spans up to 39 feet 4 inches.
Individual panels weigh up to 176 lbs and reach heights up to 12 feet. Panel width is approximately 40 inches. The lead panel can be configured as a pivot door for pass-through access without opening the full partition. The system accepts any 1/4-inch to 1/2-inch panel material, including glass, laminate, fabric-wrapped panels, and wood veneer.
Authorized PK-30 Distributor in New York City
PK-30 Folding and Sliding Partition Systems for NYC Commercial Projects
Moderco NYC is the authorized PK-30 distributor for the New York City metro area. Locally manufactured folding walls, sliding stacking systems, and curved track partitions from a factory 90 miles north of Manhattan, backed by local installation and service.
About PK-30
The Only Locally Manufactured Partition System in the Moderco NYC Portfolio
PK-30 System is a New York State manufacturer of aluminum-framed demountable wall systems, operable partitions, and sliding doors. The factory is located in High Falls, NY (Hudson Valley), with a dedicated New York City office at 212.473.8050. PK-30 is the only manufacturer in the Moderco NYC portfolio with a production facility within 90 miles of Manhattan.
Architectural Flexibility from a Single-Source Manufacturer
PK-30’s system is built on a unified aluminum profile platform that accepts any 1/4-inch, 3/8-inch, or 1/2-inch panel material, allowing unlimited design choices from a single manufacturer. All components are extruded from high-grade 6063 series aluminum alloy with 62% recycled content. The same narrow aluminum profiles are used across folding walls, sliding doors, fixed panels, and stacking partitions, creating a consistent design language throughout a project. PK-30 is a member of the U.S. Green Building Council and its products are LEED-compatible.
PK-30 Product Range
Four Product Lines for Folding, Sliding, and Stacking Configurations
PK-30 manufactures operable partition systems and architectural sliding doors across four product lines. Each line uses the same aluminum profile system, allowing mixed configurations within a single project.
Centerfold
Accordion-style center-folding wall for openings up to 39 feet. The suspension point is located at the panel center, creating a balanced stack. No bottom guide channel required. Individual panels up to 176 lbs and 12 feet tall. Lead panel configurable as a pivot door.
Variofold
Bi-folding wall system with bottom guide channel for enhanced stability. Suited for installations with more than two doors per side or heavier panel configurations. Individual panels up to 176 lbs and 12 feet tall. Stack offsets to the upper suspension track.
Variotec
Sliding stacking wall with curved track capability from 15 to 90 degrees. Modular pluggable “Perfect Curve” suspension track follows non-rectangular floor plans. Panels up to 330 lbs and 12 feet tall. Barrier-free floor surface when retracted.
Sliding Doors
Single and multi-panel architectural sliding doors up to 10 feet wide and 12 feet tall. Maximum panel weight 550 lbs. FSB full mortise locks standard with North American cylinder compatibility. Available in single, bi-parting, bypassing, pocket, and telescoping configurations.
Folding Wall System
Centerfold. Accordion Partitions for Openings Up to 39 Feet Without Floor Guides
The Centerfold is PK-30’s flagship folding wall system. It uses a center-hung suspension design that distributes panel weight evenly across the overhead track, enabling wide-span installations without the structural limitation of a bottom guide channel.
Bi-Folding Wall System
Variofold. Bi-Folding Partitions with Bottom Guide Stability
The Variofold is PK-30’s bi-folding wall system designed for installations that require the additional structural stability of a bottom guide channel. It complements the Centerfold for projects where heavier panels or longer multi-panel runs demand floor-level support.
-
Bottom Guide Channel for Heavy Panel and Multi-Door Configurations
The Variofold system uses a bottom guide channel that provides firm stability for installations with more than two doors per side. Individual panels weigh up to 176 lbs with heights up to 12 feet and widths of approximately 40 inches. The stack offsets to the upper suspension track when the partition is open.
Like all PK-30 products, the Variofold uses the same aluminum profile system and accepts the same range of 1/4-inch to 1/2-inch panel materials. This means a project can combine Centerfold (guide-free) and Variofold (guide-supported) partitions using identical visual profiles, with the guide choice determined by the structural requirements of each opening.
Sliding Stacking Wall
Variotec. Curved Track Sliding Walls for Non-Rectangular Floor Plans
The Variotec is PK-30’s sliding stacking wall system. Its defining feature is a modular pluggable track that can be curved from 15 to 90 degrees, making it the only partition system in the Moderco NYC portfolio that follows non-rectangular floor plans.
-
Perfect Curve Modular Track with 15 to 90 Degree Bends
The Variotec suspension track is a modular, pluggable system that can be assembled in straight runs or curved to follow the geometry of the floor plan. Track curves are fabricated to customer specifications within 15 to 90 degrees. Individual panels weigh up to 330 lbs and reach heights up to 12 feet.
Panels stack parallel or perpendicular to the main suspension track, and the system supports a virtually limitless number of panels in the parking area. Foot bolts anchor into dust-proof floor strikes, and the bottom guide channel can be omitted in most configurations for a barrier-free floor surface. An optional stationary egress door can be integrated into the partition run.
Finish Options
Aluminum Framing with Unlimited Panel Material Choices
PK-30’s aluminum profile system is designed to accept any panel material from 1/4-inch to 1/2-inch thick, giving architects full control over the visual appearance of the partition while using PK-30’s structural framing and hardware.
-
Standard Anodized Frames with Custom Color Options
Standard frame finishes are clear satin anodized and black satin anodized. Custom powder-coat colors are available per special order, compliant with AAMA 2603 specifications. All aluminum components use a proprietary clear silicone gasket system that cushions panel material and allows snap-in installation for easy field replacement.
Finish Options
Aluminum Framing with Unlimited Panel Material Choices
PK-30’s aluminum profile system is designed to accept any panel material from 1/4-inch to 1/2-inch thick, giving architects full control over the visual appearance of the partition while using PK-30’s structural framing and hardware.
-
Standard Anodized Frames with Custom Color Options
Standard frame finishes are clear satin anodized and black satin anodized. Custom powder-coat colors are available per special order, compliant with AAMA 2603 specifications. All aluminum components use a proprietary clear silicone gasket system that cushions panel material and allows snap-in installation for easy field replacement.
PK-30 in New York City
Manufactured 90 Miles from Manhattan with a Dedicated NYC Office
PK-30 is the only manufacturer in the Moderco NYC portfolio with a production facility in New York State. The factory in High Falls, NY is approximately 90 miles north of Manhattan, and the company maintains a New York City office for local specification support and project coordination.
-
Local Manufacturing, Shorter Lead Times, NYC Project Experience
The proximity of PK-30’s factory to the New York City market provides logistical advantages that imported or distant manufacturers cannot match. Shorter shipping distances reduce lead times and transportation costs. The NYC office at 212.473.8050 provides direct access to PK-30’s engineering and sales team for specification support, shop drawing review, and project coordination.
Local NYC Service
PK-30 Installation and Maintenance by a New York City Team
Moderco NYC provides full-service installation and ongoing maintenance for every PK-30 system sold in the NYC metro area. The proximity of PK-30’s factory means replacement parts and custom components arrive faster than from any other manufacturer in the portfolio.
-
Factory-Direct Support with Local Installation Crews
Every PK-30 installation through Moderco NYC includes shop drawing review with PK-30’s engineering team, pre-installation site measurement, track installation, panel hanging, hardware calibration, and final inspection. PK-30 products arrive factory-glazed to the greatest extent possible, reducing on-site labor and ensuring quality control.
Frequently Asked Questions
Common Questions About PK-30 Partition Systems
Answers to the questions architects and contractors ask most when evaluating PK-30 systems for NYC projects.
Both are folding wall systems, but they differ in suspension design and floor support. Centerfold uses a center-hung suspension that eliminates the need for a bottom guide channel, making it suited for wide openings up to 39 feet where floor tracks are unacceptable. Variofold uses a bottom guide channel that provides additional stability for installations with more than two doors per side or heavier panel configurations. Both systems accept the same panel materials and use the same aluminum profiles.
Yes. The Variotec sliding stacking system uses a modular pluggable track that can be curved from 15 to 90 degrees to follow non-rectangular floor plans. This is the only curved-track partition system in the Moderco NYC portfolio. Track curves are fabricated to customer specifications.
PK-30’s aluminum framing system accepts any panel material from 1/4-inch to 1/2-inch thick. Common specifications include tempered glass (clear, tinted, frosted, etched), laminate panels, fabric-wrapped acoustic panels, wood veneer, and solid-core panels. The choice of infill material determines the acoustic and fire performance of the installed partition.
PK-30 products are manufactured in High Falls, New York, approximately 90 miles north of Manhattan in the Hudson Valley. The company also maintains a New York City office at 212.473.8050 for local specification support and project coordination. PK-30 is the only manufacturer in the Moderco NYC portfolio with a production facility in New York State.
Yes. Moderco NYC is the authorized PK-30 distributor for the New York City metro area. We provide local consultation, specification support, installation, and maintenance across Manhattan, Brooklyn, Queens, the Bronx, Long Island, and New Jersey.
Yes. PK-30 is a member of the U.S. Green Building Council. All aluminum components are extruded from 6063 series alloy with 62% recycled content. Products contribute to multiple LEED v4/v4.1 credits including Environmental Product Declarations, Sourcing of Raw Materials, Material Ingredients, Design for Flexibility, Low-Emitting Materials, and Daylight. PK-30 provides manufacturer’s letters certifying LEED credit compliance upon request.
What Our Clients Say
NYC Professionals on Working with Moderco NYC and PK-30
Feedback from architects, contractors, and facility managers who have specified or installed PK-30 systems through Moderco NYC.
Specify PK-30 for Your NYC Project
Ready to Evaluate PK-30 Partition Systems for Your Next Project
Share your project details and our team will recommend the right PK-30 product line based on your opening dimensions, track configuration, panel material preferences, and timeline. Local consultation, specification support, and installation across the NYC metro area.
